| Surface: | Glossy | Power Source: | Electric |
|---|---|---|---|
| Engine Type: | Electric | Product name: | Tungsten carbide rings |
| Material: | 100% pure tungsten carbide powder | Advantage: | High Wear Resistance |
| Size: | Customer Required | Packing: | Paper Case |
| Application: | Mechanical seal | Shape: | Circle |
| Grade: | YG8/YG9C/YG11C | MOQ: | 5 PIECES |
| Color: | Black | ||
| 강조하다: | 초경 텅스텐 카바이드 씰 링,100% 텅스텐 카바이드 씰 링,고밀봉 텅스텐 카바이드 씰 링 |
||
등급 | 구성 (체중%) | 물리적 특성 | |||||||||||||
밀도/cm³ (± 0.1) | Headnesshra (± 0.5) | TRS MPA (Min) | 다공성 | ||||||||||||
WC | NI | 티 | TAC | 알파벳 | |||||||||||
KD115/yg6x | 93.5 | 6.0 | - | 0.5 | 14.90 | 93.0 | 2700 | A02/B00/C00 | 0.6-0.8 | ||||||
KD335/yg10x | 89.0 | 10.5 | - | 0.5 | 14.40 | 91.8 | 3800 | A02/B00/C00 | 0.6-0.8 | ||||||
kg6/yg6 | 94.0 | 6.0 | - | - | 14.90 | 90.5 | 2500 | A02/B00/C00 | 1.2-1.6 | ||||||
KG8/YG8 | 92.0 | 8.0 | - | - | 14.75 | 90.0 | 3200 | A02/B00/C00 | 1.2-1.6 | ||||||
KG9/YG9 | 91.0 | 9.0 | - | - | 14.60 | 89.0 | 3200 | A02/B00/C00 | 1.2-1.6 | ||||||
kg9c/yg9c | 91.0 | 9.0 | - | - | 14.60 | 88.0 | 3200 | A02/B00/C00 | 1.6-2.4 | ||||||
KG10/KG10 | 90.0 | 10.0 | - | - | 14.50 | 88.5 | 3200 | A02/B00/C00 | 1.2-1.6 | ||||||
KG11/yg11 | 89.0 | 11.0 | - | - | 14.35 | 89.0 | 3200 | A02/B00/C00 | 1.2-1.6 | ||||||
Kg11c/yg11c | 89.0 | 11.0 | - | - | 14.40 | 87.5 | 3000 | A02/B00/C00 | 1.6-2.4 | ||||||
KG13/YG13 | 87.0 | 13.0 | - | - | 14.20 | 88.7 | 3500 | A02/B00/C00 | 1.2-1.6 | ||||||
KG13C/YG13C | 87.0 | 16.0 | - | - | 14.20 | 87.0 | 3500 | A02/B00/C00 | 1.6-2.4 | ||||||
KG15/YG15 | 85.0 | 15.0 | - | - | 14.10 | 87.5 | 3500 | A02/B00/C00 | 1.2-1.6 | ||||||
KG15C/YG15C | 85.0 | 15.0 | - | - | 14.00 | 86.5 | 3500 | A02/B00/C00 | 1.6-2.4 | ||||||
KD118/YG8X | 91.5 | 8.5 | - | - | 14.50 | 93.6 | 3800 | A02/B00/C00 | 0.4-0.6 | ||||||
KD338/yg12x | 88.0 | 12.0 | - | - | 14.10 | 92.8 | 2200 | A02/B00/C00 | 0.4-0.6 | ||||||
KD25/P25 | 77.4 | 8.5 | 6.5 | 6.0 | 12.60 | 91.8 | 2200 | A02/B00/C00 | 1.0-1.6 | ||||||
KD35/P35 | 69.2 | 10.5 | 5.2 | 13.8 | 12.70 | 91.1 | 2500 | A02/B00/C00 | 1.0-1.6 | ||||||
KD10/M10 | 83.4 | 7.0 | 4.5 | 4.0 | 13.25 | 93.0 | 2000 | A02/B00/C00 | 0.8-1.2 | ||||||
KD20/M20 | 79.0 | 8.0 | 7.4 | 3.8 | 12.33 | 92.1 | 2200 | A02/B00/C00 | 0.8-1.2 | ||||||
등급 | 구성 (체중%) | 물리적 특성 | 등가 에게 국내의 | |||||||||||
밀도/cm³ (± 0.1) | Headnesshra (± 0.5) | TRS MPA (Min) | 다공성 알파벳 | 곡물 크기 (μm) | ||||||||||
WC | NI | 티 | ||||||||||||
KDN6 | 93.8 | 6.0 | 0.2 | 14.6-15.0 | 89.5-90.5 | 1800 | A02 \ B00 \ C00 | 0.8-2.0 | YN6 | |||||
KDN7 | 92.8 | 7.0 | 0.2 | 14.4-14.8 | 89.0-90.0 | 1900 | 0.8-1.6 | YN7 | ||||||
KDN8 | 91.8 | 8.0 | 0.2 | 14.5-14.8 | 89.0-90.0 | 2200 | 0.8-2.0 | YN8 | ||||||
KDN12 | 87.8 | 12.0 | 0.2 | 14.0-14.4 | 87.5-88.5 | 2600 | 0.8-2.0 | YN12 | ||||||
KDN15 | 84.8 | 15.0 | 0.2 | 13.7-14.2 | 86.5-88.0 | 2800 | 0.6-1.5 | YN15 | ||||||
