Custom Cemented Tungsten Carbide Alloy Cylindrical Sleeve for High Wear Resistance in PDC Drilling Oil Equipment

Custom Cemented Tungsten Carbide Alloy Cylindrical Sleeve for High Wear Resistance in PDC Drilling Oil Equipment
Custom Cemented Tungsten Carbide Alloy Cylindrical Sleeve for High Wear Resistance in PDC Drilling Oil Equipment Custom Cemented Tungsten Carbide Alloy Cylindrical Sleeve for High Wear Resistance in PDC Drilling Oil Equipment Custom Cemented Tungsten Carbide Alloy Cylindrical Sleeve for High Wear Resistance in PDC Drilling Oil Equipment Custom Cemented Tungsten Carbide Alloy Cylindrical Sleeve for High Wear Resistance in PDC Drilling Oil Equipment Custom Cemented Tungsten Carbide Alloy Cylindrical Sleeve for High Wear Resistance in PDC Drilling Oil Equipment Custom Cemented Tungsten Carbide Alloy Cylindrical Sleeve for High Wear Resistance in PDC Drilling Oil Equipment

큰 이미지 :  Custom Cemented Tungsten Carbide Alloy Cylindrical Sleeve for High Wear Resistance in PDC Drilling Oil Equipment

제품 상세 정보:
원래 장소: 중국
결제 및 배송 조건:
최소 주문 수량: 5
가격: $10-23
접촉

Custom Cemented Tungsten Carbide Alloy Cylindrical Sleeve for High Wear Resistance in PDC Drilling Oil Equipment

설명
재료: 100% 순수 텅스텐 카바이드 분말 모양: 원통형
표면: 광택 색상: 검은색
등급: yg8/yg9c/yg11c 밀도: 14.90 g/cm³
경도: 93.0 HRA Trs: 2700 MPa
다공성: A02/B00/C00 곡물 크기: 0.6-0.8 μm
외경: 16.41 mm 내 직경: 14.05 mm
기공 직경: 12.70 mm 길이: 25.40 mm
스텝 길이: 1.00 mm
강조하다:

Custom Tungsten Carbide Sleeve

,

Cemented Tungsten Carbide Alloy Bushing

,

Cylindrical Carbide Liner

Custom Cemented Tungsten Carbide Alloy Cylindrical Thin Walled Casing Seal Sleeve Bushing Liner for PDC Drilling Oil Equipment
Product Description
Custom Cemented Tungsten Carbide Alloy Cylindrical Sleeve for High Wear Resistance in PDC Drilling Oil Equipment 0 Custom Cemented Tungsten Carbide Alloy Cylindrical Sleeve for High Wear Resistance in PDC Drilling Oil Equipment 1
Product Parameters
Custom Cemented Tungsten Carbide Alloy Cylindrical Sleeve for High Wear Resistance in PDC Drilling Oil Equipment 2 Custom Cemented Tungsten Carbide Alloy Cylindrical Sleeve for High Wear Resistance in PDC Drilling Oil Equipment 3
GradeComposition (% in weight)Physical PropertiesGrain size (μm)

WCNiTiTaCDensity g/cm³ (±0.1)Hardness HRA (±0.5)TRS Mpa (min)Porosity A/B/C
KD115/YG6X93.56.0-0.514.9093.02700A02/B00/C000.6-0.8
KD335/YG10X89.010.5-0.514.4091.83800A02/B00/C000.6-0.8
KG6/YG694.06.0--14.9090.52500A02/B00/C001.2-1.6
KG8/YG892.08.0--14.7590.03200A02/B00/C001.2-1.6
KG9/YG991.09.0--14.6089.03200A02/B00/C001.2-1.6
KG9C/YG9C91.09.0--14.6088.03200A02/B00/C001.6-2.4
KG10/KG1090.010.0--14.5088.53200A02/B00/C001.2-1.6
KG11/YG1189.011.0--14.3589.03200A02/B00/C001.2-1.6
KG11C/YG11C89.011.0--14.4087.53000A02/B00/C001.6-2.4
KG13/YG1387.013.0--14.2088.73500A02/B00/C001.2-1.6
KG13C/YG13C87.013.0--14.1087.03500A02/B00/C001.6-2.4
KG15/YG1585.015.0--14.0087.53500A02/B00/C001.2-1.6
KG15C/YG15C85.015.0--14.5086.53500A02/B00/C001.6-2.4
KD118/YG8X91.58.5--14.1093.63800A02/B00/C000.4-0.6
KD338/YG12X88.012.0--12.6092.82200A02/B00/C000.4-0.6
KD25/P2577.48.56.56.012.7091.82200A02/B00/C001.0-1.6
KD35/P3569.210.55.213.813.2591.12500A02/B00/C001.0-1.6
KD10/M1083.47.04.54.012.3393.02000A02/B00/C000.8-1.2
KD20/M2079.08.07.43.812.3392.12200A02/B00/C000.8-1.2
NOTE: Customization available per customer drawing or actual sample
SpecificationOD (D:mm)ID (D1:mm)Pore (d:mm)Length (L;mm)Step length (L1:mm)
0116.4114.0512.7025.401.00
0216.4114.0512.7031.751.00
0322.0418.8615.7531.753.18
0422.0418.8615.7550.803.18
0516.0013.9010.3176.203.18
0622.0018.8814.3025.403.18
0724.0021.0016.0075.003.00
0822.9021.0015.0075.003.00
0919.5016.9012.7050.004.00
1036.8032.8026.0055.004.00
Details Images
Custom Cemented Tungsten Carbide Alloy Cylindrical Sleeve for High Wear Resistance in PDC Drilling Oil Equipment 4
Why Choose Us
Custom Cemented Tungsten Carbide Alloy Cylindrical Sleeve for High Wear Resistance in PDC Drilling Oil Equipment 5
Company Profile
Custom Cemented Tungsten Carbide Alloy Cylindrical Sleeve for High Wear Resistance in PDC Drilling Oil Equipment 6
Exhibition
Custom Cemented Tungsten Carbide Alloy Cylindrical Sleeve for High Wear Resistance in PDC Drilling Oil Equipment 7 Custom Cemented Tungsten Carbide Alloy Cylindrical Sleeve for High Wear Resistance in PDC Drilling Oil Equipment 8Custom Cemented Tungsten Carbide Alloy Cylindrical Sleeve for High Wear Resistance in PDC Drilling Oil Equipment 9
Frequently Asked Questions
How to obtain an accurate quotation from Kedel Tools?
Please provide us with specific material requirements, precise dimensions, and drawings that include tolerances and quantities for different models. This will allow us to provide you with a more accurate quote.
How does our company ensure the quality of its products?
We have inspection processes from raw material production, to finished product grinding, to cleaning and packaging. Each process also has sampling inspection. If the product in the previous process is not qualified, it will never enter the second process. Ensure the quality of the finished product.
How long does a typical production cycle take?
For products that are often in stock, they can be shipped directly. For customized products, the specific judgment is based on the difficulty level of product processing. Normally, non-standard products require 20-25 days for production.
What is our company's payment method?
We accept wire transfers, L/C, ALIPAY, WEST UNION, PAYPAL, 100% payment is required for standard products before shipment, 50% for non-standard products before production, and 50% before shipment.
In our journey at Kedel Technology Co., Ltd. in Chengdu, every encounter with you is our honor. We are well aware that being able to stop here among the many choices is our greatest support and recognition. Your satisfaction is our relentless pursuit, and every positive review and repurchase is the driving force that inspires us to keep moving forward.
